3 WORK
22
3.12 Disconnecting the negative cable of the 12-V battery
Preparatory work
– Remove the seat. ( p. 17)
R01414-10
Main work
–
Disconnect negative cable
1
of the 12-V battery.
3.13 Connecting the negative cable of the 12-V battery
T02638-10
Main work
–
Connect negative cable
1
of the 12-V battery.
Guideline
Screw, battery termi-
nal
M5 2.5 Nm
(1.84 lbf ft)
Contact disk
A
must be mounted under screw
2
and
cable lug
3
with the claws toward the battery terminal.
Finishing work
– Mount the seat. ( p. 17)
3.14 Opening the fuel tank filler cap
Danger
Fire hazard Fuel is highly flammable.
The fuel in the fuel tank expands when warm and can escape if overfilled.
– Do not fuel the vehicle in the vicinity of open flames or lit cigarettes.
– Switch off the engine for refueling.
– Make sure that no fuel is spilled; particularly not on hot parts of the vehicle.
– If any fuel is spilled, wipe it off immediately.
– Observe the specifications for refueling.
