6 CONTROLS
20
6.15 Plug-in stand (All SX‑F models)
H02629-10
The support for plug-in stand
1
is the left side of the wheel spin-
dle.
The plug-in stand is used to park the motorcycle.
The plug-in stand is used as a fork locker when transporting the
motorcycle.
Info
Remove the plug-in stand before riding.
The tool can be attached to the plug-in stand holders.
6.16 Side stand (XC‑F US)
401943-10
The side stand
1
is located on the left of the vehicle.
401944-10
The side stand is used for parking the motorcycle.
Info
When you are riding, side stand
1
must be folded up and
secured with rubber strap
2
.
