CONTROLS 6
23
6.17 Factory Start (HERLINGS REPLICA, FACTORY EDITION)
S02283-10
The Factory Start
1
is mounted on the right fork protector.
Possible states
•
A
Factory Start is deactivated – The fork is in the normal
operating mode.
•
B
Factory Start is activated – The fork is compressed and
the front of the motorcycle is lowered.
Activating the Factory Start lowers the front of the motorcycle,
which then causes the front wheel to lift off the ground when
accelerating.
When the fork compresses for the first time, the Factory Start lock
button is released automatically. From this point on, the fork oper-
ates as if the Factory Start were deactivated or not installed.
