SERVICE WORK ON THE CHASSIS 11
89
F01575-10
(XC‑F US)
–
Fill bleeding syringe
4
with the appropriate hydraulic
fluid.
Syringe (50329050000)
Brake fluid DOT 4 / DOT 5.1 ( p. 150)
– On the clutch slave cylinder, remove the protection cap
and mount bleeding syringe
4
with appropriate hose
piece at the bleeder screw
5
.
–
Only loosen bleeder screw
5
on the clutch slave cylinder
to the point where filling is possible.
F00166-10
– Now press the fluid into the system until it emerges from
hole
6
of the master cylinder without bubbles.
– Now and then, extract the fluid from the master cylinder reser-
voir to prevent overflow.
– Tighten the bleeder screw and remove the bleeding syringe
with the hose. Mount the protection cap.
– Correct the fluid level of the hydraulic clutch.
Guideline
Fluid level below container
rim
4 mm (0.16 in)
– Position the cover with the membrane. Mount and tighten the
screws.
