6 CONTROLS
16
6.1 Hand brake lever
M01656-10
Hand brake lever
1
is fitted on the right side of the handlebar.
The hand brake lever is used to activate the front brake.
6.2 Throttle grip
M01656-11
The throttle grip
1
is fitted on the right side of the handlebar.
After activation, the vehicle initially does not react to the throttle
grip to prevent accidental acceleration.
The throttle grip must be closed beyond the basic position to acti-
vate the throttle response.
Only then does the vehicle switch to ready mode.
6.3 On/Off button
M01673-10
The On/Off button
1
is located on the right side of the
Powerpack LV.
Possible states
• Vehicle switched off – In this operating state, the vehicle is
deactivated.
• Vehicle in standby mode – In this operating state, the vehicle
is activated.
6.4 Magnetic switch on handlebar
M01657-10
The holder for the red magnetic switch
1
is located on the left
side of the handlebar.
Possible states
• Magnetic switch mounted on handlebar – When the mag-
netic switch is mounted on the handlebar, the vehicle can be
activated and ridden.
• Magnetic switch removed from handlebar – When the mag-
netic switch is removed from the handlebar, the vehicle can-
not be activated or ridden.
