15 WHEELS, TIRES
76
15.1 Removing the front wheel
Preparatory work
– Raise the motorcycle with a lift stand. ( p. 45)
M01697-10
Main work
–
Remove screw
1
.
–
Loosen screws
2
.
M01698-10
Warning
Danger of accidents Damaged brake discs reduce the
braking effect.
– Always lay the wheel down in such a way that the
brake disc is not damaged.
– Hold the front wheel and remove the wheel spindle. Take the
front wheel out of the fork.
Info
Do not actuate the hand brake lever when the front
wheel is removed.
H00934-10
–
Remove spacers
3
.
15.2 Installing the front wheel
Warning
Danger of accidents Oil or grease on the brake discs reduces the braking effect.
– Always keep the brake discs free of oil and grease.
– Clean the brake discs with brake cleaner when necessary.
