49PERIODIC SERVICE
PERIODIC SERVICE
To avoid personal injury:
A Do not work under any hydraulically supported
devices. They can settle, suddenly leak down,
or be accidentally lowered. If necessary to work
under tractor or any machine elements for
servicing or adjustment, securely support them
with stands or suitable blocking beforehand.
HOW TO OPEN THE HOOD
To avoid personal injury from contact with moving
parts;
A Never open the hood or engine side cover while
the engine is running.
A Do not touch muffler or exhaust pipes while
they are hot;
Severe burns could result.
BHood
To open the hood, rotate the knob to release the latch and
open the hood.
BEngine Cover
To remove the engine cover, loosen the knob bolts. Close
the hood half way and fix the band to the hood. Then, hold
the hood with the band, and pull forward as shown in
following figure.
In the above procedure, be careful not to hit the engine
cover against the head lights.
It is not necessary to detach the engine cover for daily
check.
(1) Knob
(2) Hood
(A) "ROTATE"
(1) Knob bolts
(1) Band

Kubota BX1870 Specifications

General

Engine Type	Diesel
Engine Power	18 hp
Transmission	Hydrostatic
Fuel Capacity	6.6 gallons
Wheelbase	55.1 inches
Type	Sub-Compact Utility Tractor
Engine	Kubota D722
PTO Power	13.5 hp
Number of Cylinders	3
Cooling	Liquid
Drive	4WD
Drive Type	4WD
Width	44.5 inches
Hydraulic System Type	Open center
PTO Speed	540 RPM
Displacement	0.719 L
Fuel Tank Capacity	6.6 gallons
Gears	Infinite (2-range) forward and reverse
Front Tire Size	18x8.5-10
Rear Tire Size	26x12-12
