Operation
59
Horizontal seat adjustment (seat stand-off) - U35-3α2
Pull the horizontal seat adjustment lever (1) sideways and move
the seat to the desired position by moving it forward or back,
then release the lever.
Check that the seat is locked into place.
Spring adjustment (driver's weight) - U35-3α2
The seat can be set to the weight of the driver with the spring
adjustment grip (1). Turning the spring adjustment grip towards
"+" increases spring tension (heavier operator), turning the grip
towards "-" reduces spring tension (lighter operator). Adjust the
seat so that a comfortable cushioning is achieved.
Backrest adjustment - U35-3α2
By turning the spring adjustment grip (1) you can adjust the
desired position of the backrest. The backrest should be
adjusted so that the operator can safely operate the control
levers with the back resting completely on the backrest.
