S-16
03-M-E3B, 03-M-DI-E3B, 03-M-E3BG WSM
DIESEL ENGINE
FUEL SYSTEM
W1123952
Item Factory Specification Allowable Limit
Injection Pump
[D1503-M], [V2003-M-T-BG]
Injection Timing 0.253 to 0.279 rad
(14.5 to 16.0 °) before
T.D.C.
–
Injection Pump
[D1703-M], [D1803-M]
[V2003-M], [V2203-M]
[V2403-M]
Injection Timing 0.271 to 0.296 rad
(15.5 to 17.0 °) before
T.D.C.
–
Injection Pump
[V2403-M-T]
Injection Timing 0.132 to 0.157 rad
(7.55 to 9.05 °) before
T.D.C.
–
Injection Pump
[D1803-M-DI], [V2403-M-DI]
Injection Timing 0.0742 to 0.100 rad
(4.25 to 5.75 °) before
T.D.C.
–
Injection Pump
[V2403-M-DI-T]
Injection Timing 0.0829 to 0.109 rad
(4.75 to 6.25 °) before
T.D.C.
–
Injection Pump
[D1703-M-BG], [V2003-M-BG]
[V2203-M-BG], [V2403-M-BG]
Injection Timing 0.236 to 0.261 rad
(13.5 to 15.0 °) before
T.D.C.
–
Pump Element
[D1503-M], [D1703-M]
[D1803-M], [V2003-M]
[V2203-M], [V2403-M]
[V2403-M-T]
[D1703-M-BG], [V2003-M-BG]
[V2003-M-T-BG], [V2203-M-BG]
[V2403-M-BG]
Fuel Tightness – 13.73 MPa
140.0 kgf/cm
2
1991 psi
Pump Element
[D1803-M-DI], [V2403-M-DI]
[V2403-M-DI-T]
Fuel Tightness – 18.63 MPa
190.0 kgf/cm
2
2702 psi
Delivery Valve
[D1503-M], [D1703-M]
[D1803-M], [V2003-M]
[V2203-M], [V2403-M]
[V2403-M-T]
[D1703-M-BG], [V2003-M-BG]
[V2003-M-T-BG], [V2203-M-BG]
[V2403-M-BG]
Fuel Tightness 10 seconds
13.73 → 12.75 MPa
140.0 → 130.0 kgf/cm
2
1991 → 1849 psi
5 seconds
13.73 → 12.75 MPa
140.0 →
130.0 kgf/cm
2
1991 → 1849 psi
Delivery Valve
[D1803-M-DI], [V2403-M-DI]
[V2403-M-DI-T]
Fuel Tightness 10 seconds
18.63 → 17.65 MPa
190.0 → 180.0 kgf/cm
2
2702 → 2560 psi
5 seconds
18.63 → 17.65 MPa
190.0 →
180.0 kgf/cm
2
2702 → 2560 psi
KiSC issued 07, 2008 A
