S-17
03-M-E3B, 03-M-DI-E3B, 03-M-E3BG WSM
DIESEL ENGINE
FUEL SYSTEM (Continued)
W1041294
Item Factory Specification Allowable Limit
Injection Nozzle
[D1503-M], [D1703-M]
[D1803-M], [V2003-M]
[V2203-M], [V2403-M]
[V2403-M-T]
[D1703-M-BG], [V2003-M-BG]
[V2003-M-T-BG], [V2203-M-BG]
[V2403-M-BG]
Injection Pressure 13.73 to 14.70 MPa
140.0 to 150.0 kgf/cm
2
1992 to 2133 psi
–
Injection Nozzle
[D1803-M-DI], [V2403-M-DI]
[V2403-M-DI-T]
Injection Pressure
(1st stage)
18.64 to 20.10 MPa
190.0 to 205.0 kgf/cm
2
2703 to 2915 psi
–
Injection Nozzle Valve Seat
[D1503-M], [D1703-M]
[D1803-M], [V2003-M]
[V2203-M], [V2403-M]
[V2403-M-T]
[D1703-M-BG], [V2003-M-BG]
[V2003-M-T-BG], [V2203-M-BG]
[V2403-M-BG]
Valve Seat
Tightness
When the pressure is
12.75 MPa
(130.0 kgf/cm
2
, 1849
psi), the valve seat must
be fuel tightness.
–
Injection Nozzle Valve Seat
[D1803-M-DI], [V2403-M-DI]
[V2403-M-DI-T]
Valve Seat
Tightness
When the pressure is
16.67 MPa
(170.0 kgf/cm
2
, 2418
psi), the valve seat must
be fuel tightness.
–
