Kubota V2403-M-DI-T User Manual

S-18
03-M-E3B, 03-M-DI-E3B, 03-M-E3BG WSM
DIESEL ENGINE
ELECTRICAL SYSTEM
W1125417
Item Factory Specification Allowable Limit
Starter
Commutator
[D1503-M], [D1703-M]
[V2003-M], [V2203-M]
[D1803-M-DI]
[D1703-M-BG], [V2003-M-BG]
[V2003-M-T-BG], [V2203-M-BG]
Commutator
[D1803-M], [V2403-M]
[V2403-M-DI], [V2403-M-T]
[V2403-M-DI-T]
[V2403-M-BG]
Mica
[D1503-M], [D1703-M]
[D1803-M], [V2003-M]
[V2203-M], [V2403-M]
[V2403-M-T]
[D1803-M-DI], [V2403-M-DI]
[V2403-M-DI-T]
[D1703-M-BG], [V2003-M-BG]
[V2003-M-T-BG], [V2203-M-BG]
Mica
[V2403-M-BG]
Brush
[D1503-M], [D1703-M]
[V2003-M], [V2203-M]
[D1803-M-DI]
[D1703-M-BG], [V2003-M-BG]
[V2003-M-T-BG], [V2203-M-BG]
Brush
[D1803-M], [V2403-M]
[V2403-M-DI], [V2403-M-T]
[V2403-M-DI-T]
Brush
[V2403-M-BG]
Brush Holder and Holder Support
O.D.
O.D.
Under Cut
Under Cut
Length
Length
Length
Resistance
30.0 mm
1.18 in.
35.0 mm
1.38 in.
0.45 to 0.75 mm
0.018 to 0.029 in.
0.55 to 0.85 mm
0.022 to 0.033 in.
15.0 mm
0.591 in.
15.0 mm
0.591 in.
15.0 mm
0.591 in.
Infinity
29.0 mm
1.14 in.
34.0 mm
1.34 in.
0.20 mm
0.0079 in.
0.20 mm
0.0079 in.
11.0 mm
0.433 in.
9.0 mm
0.35 in.
12.0 mm
0.472 in.
–
Alternator
Stator
Rotor
Slip Ring
Brush
No-load voltage
Resistance
Resistance
O.D.
Length
More than 13.5 V
Less than 1.0 Ω
2.9 Ω
14.4 mm
0.567 in.
10.5 mm
0.413 in.
–
–
–
14.0 mm
0.551 in.
8.4 mm
0.33 in.
Glow Plug Resistance Approx. 0.9 Ω –
