Instructions for work
Disc mower
GMD240-280-310
51
KN204AGB H
Swathing system
The swathing system comprises the following
component:
• 1 outer swath wheel (Adjustable).
- Position the swath wheel in order to obtain an angle
between 16° (A) and 32° (A’).
- Check that there is a minimum
clearance (J) of 15 mm (0.59’’) between
the cone rib and the swath wheel.
