Instructions for work
Disc mower
GMD240-280-310
55
KN204AGB H
- If the break-away latch releases too easily after reset,
tighten nut (1) to increase spring washer compression
slightly.
Basic adjustment:
L= 95 mm (3.7’’).
In case of clogging:
- Lift up the front guard.
- Remove foreign body.
- Check that the mowing unit has not been damaged.
- Check rotating components for damage.
- Lower and lock front guard.
- Respect spring washer layout.
For normal functioning of the break-away latch,
measure L must never be below 91 mm (3.60").
Before carrying out any maintenance or
repairs on the machine, switch off the tractor
engine, remove ignition key, wait until all
moving parts have come to a standstill and
apply park brake.
