11. - Maintenance and storage
FC3160TCD-3560TCD-4060TCD
79
KN284DGB B
Mower conditioner
Intermediate PTO shaft 2(d):
- Step on the self-adhesive non-slip patches (1) to
access the other greasers.
1
- Grease the U-joints.
- Loosen screw (1).
- Pivot cover (2) to access greaser.
- Grease
• Grease PTO shaft U-joint.
• Drive shaft tubes.
- Reinstall cover plate.
1
2
