Spreading Operation
85
B
AXIS 20.1AXIS 20.1
B.5 Setting the working width
B.5.1 Choosing the correct spreading disc
Various spreading discs are available for implementation of the working width de-
pending on the fertiliser type.
There are two different, permanently installed vanes on every spreading disc.
The vanes are marked according to their model.
Spreading disc
type:
Working width
S2 12-18 m
S4 18-28 m
n WARNING
Risk of injury from rotating machine components
Contact with the spreading equipment (spreading discs, spread-
ing vanes) may injure, crush or cut off body parts. Body parts or
objects may be caught and pulled in.
 Do not remove deflectors mounted on the spreader hopper.
Spreading disc type Spreading disc left Spreading disc right
S2 uncoated S2-L-170
S2-L-240
S2-R-170
S2-R-240
S2 coated (optional) S2-L-170 VxR
S2-L-240 VxR
S2-R-170 VxR
S2-R-240 VxR
S4 uncoated S4-L-200
S4-L-270
S4-R-200
S4-R-270
S4 coated (optional) S4-L-200 VxR
S4-L-270 VxR
S4-R-200 VxR
S4-R-270 VxR
