KUHN EL32 - Page 33

Instructions for work
Rotary cultivators
EL32
31

Rear hood adjustment
The rear hood adjustment is one of the factors governing
the tilth degree.
- Adjust hood height using chains (1).
To obtain a coarser tilth, the hood can be raised.
To obtain a finer tilth, the hood can be lowered.
