Putting into service
Mower conditioner
FC302RG - FC352RG
31
KN271BGB C
Hydraulic connections
- Connect the 2 hydraulic hoses of the drawbar shift
cylinder to a double acting valve (1).
- Connect the mowing unit lift cylinder to a single acting
valve (2).
Electrical connections
- Connect machine 7-pin plug on the tractor 7-pin
socket.
1
2
1
When optional equipment is used, follow specific
procedures mentioned in the related section:
Chain stroke limiter.
