Mower conditioner
68
FC883RA
Instructions for work
On slopes
During work, the machine frame can be offset laterally
to avoid strips of uncut crop when turning or on slopes.
During work on slopes, the mowing unit overlap can be
insufficient due to the tractor rear axle side drift.
To adjust the overlap:
- Offset frame using the double acting hydraulic valve.
- Position main frame in line with the tractor on even
field.
The frame must be offset uphill.
The offset increases the overlap up to
D = 270 mm (10’6’’).
