Instructions for transport
Mower conditioner
FC883RA
45
$INSTRUCTIONS FOR TRANSPORT
1. Putting the machine into transport
position
From the working position:
- Release and fold side guards upwards using 18mm
box spanner supplied with the machine (1).
- Lock guards using bracket (2) and lynch pin (3).
- Fold stop rod (4).
- Lower conveyors (a).
- Lower transport wheels (b).
- Lower the tractor lift linkage until the transport wheel
touch the ground.
Before placing the machine into transport
position:
- Wait until the rotating parts have come
to a complete stop.
- Check that nobody is within the machine
pivoting area.
- If there is someone, make sure the
person moves away.
If the torque limiter has become very hot due
to slippage, wait for it to cool down before
pivoting the machine into transport position.
