Mower conditioner
44
FC883RA
Putting into service
- Check that all suspension system valves are shut-off.
- Disconnect hydraulic hoses and electric plug.
- Place hydraulic hoses and electric signalling plug in
their respective supports (4).
- Disconnect and store 19 pin plug in holder (5).
- Detach the top link from the machine end.
- Uncouple the lower links.
- Lower the tractor three-point linkage.
The machine is uncoupled.
Position a: Circuit open.
Position b: Circuit closed.
