Putting into service
Mower conditioner
FC883RA
43
Uncoupling the machine
- Lower transport wheels.
- Unlock and remove lynch pin (1).
- Remove pin (2).
- Lower parking stand (3).
- Insert pin in one of the 3 parking stand upper holes
corresponding to parking position (4).
- Insert and lock lynch pin (1).
- Proceed the same way on each parking stand.
- Lower the tractor three-point linkage to rest the
machine on the ground.
- Uncouple PTO shaft (2) and place it in its holder (1).
The machine must be uncoupled in working
position.
