PLEASE UNSURE YOU SCREW THE WIFI ANTENNAS ONTO THE WIFI PLUGS AND
THE LTE (4G) ANTENNAS ON TO THE LTE PLUGS.
THERE ARE LABELS ON THE ANTENNAS – DO NOT MIX THEM UP
SIM connection
1
Insert a standard (large) size SIM card ONLY
According to the interface identification on the device, insert the
SIM card, and pay attention to the metal contacts and the cut
out angle direction of the card. Do not insert a small size card, it
will be lost inside
SIM
15 x 25 (mm)
Micro SIM
12 x 15 (mm)
Nano SIM
8.8 x 12.3 (mm)
Micro SIM or Nano SIM cards need to be inserted into our card
adapter before use or they will not be accepted by the Connect.
As shown in the figure, the SIM card is facing
inward with the missing angle, and the metal
chip is facing downward. Insert the card slot,
and then fasten it when you hear the click. Be
sure to insert it correctly.
1
