4.4 PAS Level Selection
Short press the "UP" or “DOWN” button to switch the PAS level, the motor output power will be
changed accordingly by the PAS level of E-bike. The default range of PAS level is 0-5 levels. Level 1 is
the lowest output level, and the level 5 is the highest output power level of the motor. The default
level is level 1.
4.5 Battery Indicator
The battery power is shown as a percentage bar. When the battery is fully charged, the power bar
shows 100%
Battery indicator
4.6 Lights turn on/off indication
Long press "UP" button to turn on head light. Long press "UP" button again to turn off the head light.
Light indication interface
4.7 Error code indication
When the e-bike electronic control system fails, the display will automatically indicate the error code.
For the definition of detailed error codes, see appendix 1.
