Kuppersbusch B6330.0 - Description of the Oven; Control Panel

22
User’s Guide
Description of the oven
1
Control panel
2
Door lock (only for
pyrolytic models)
3
Grill element
4
Tray supports
5
Grid shelf
6
Tray
7
Hinge
8
Inner Glass
9
Air cooling outlet
10
Unit mounting
11
Lamp
12
Back Wall Panel
13
Fan
14
Oven Seal
15
Door
1
10
12
13
14
15
5
6
7
8
3
2
4
9
11
Control panel
4
Pilot light cooking zone.
5
Cooking zone controls.
1
Temperature control dial.
2
Electric clock/timer.
3
Function control dial.
3 2 1
B6335.0 / B6330.0
Models
5 4 3 2 1
H6120.0 Models
