KUPPET 1022101300 - Specifications; Dimensions and Connections; Rating Information

5
SPECIFICATIONS
1) DIMENSIONS/CONNECTIONS
2) Rating
MODEL
POWER SUPPLY VOLTAGE 1Phase, 110-120/60Hz
ELECTRICAL PROTECTIO N CLASS
I
ICE MAKING RATING (Amps)
1.5 Amp
ICE HARVEST RATING (Amps)
2.3 Amp
ICE MAKING CAPACITY (lbs/24H)
66 lbs / 24Hour*
REFRIGERANT CHARGE
R600a, 1.8 Oz/51g
VESICANT
C5H10
UNIT DIMENSIONS(W X D X H) (in) 13.6x13.35 x23.7
NET W EIGHT/GR OSS WEIGHT(ibs) lbs
CONNECTION POWER CORD---- 18 AWG
WATER SUPP LY----1/4 inches Diameter
DRAIN PIPE ---Φ5/8 inches
SYLPHON BELLOWSS
MAX ICE STORAGE CAPACITY(KG)
4 Kg
ACCESSORIES
ICE SCOOP, INSTALLATION KITS
RUNNING CONDITION S ROOM TEMP 50-110 Fahrenheit
WATER SUPP LY TEMP 41-95 Fahre nheit
WATER SUPP LY PRESSURE** 0.04-0.6 MPa
NOTE *: TESTED AT 70 Fahrenheit RO OM TEMPERATURE AND 50 Fahrenheit WATER TEMPERATURE.
**. FOR AUTOMATIC WATER SUPPLYING
1022101300
40.7
