KUPPET HZB-45 - SPECIFICATIONS; DIMENSIONS;CONNECTIONS; Rating

5
SPECIFICATIONS
1) DIMENSIONS/CONNECTIONS
2) Rating
MODEL
HZB-45
POWER SUPPLY VOLTAGE 1Phase, 110-120/60Hz
ICE MAKING RATING (Amps) 2.2 Amp
ICE HARVEST RATING (Amps) 2.5 Amp
ICE MAKING CAPACITY (KG/24H) 45kg/24Hour
*
REFRIGERANT CHARGE R290,3.35Oz/95g
VESICANT C5H10
UNIT DIMENSIONS(W X D X H) (mm) 448 x 400 x 798
NET WEIGHT/GROSS WEIGHT(KG)
28.3Kg
CONNECTION POWER CORD---- 18AWG
WATER SUPPLY----6.35mm diamete
DRAIN----Φ16
SYLPHON BELLOWSS(REAR)
WATER CONSUMPTION(L/24H) 50L
MAX ICE STORAGE CAPACITY(KG) 15Kg
ACCESSORIES SHOVEL, INSTALLATION KITS
RUNNING CONDITIONS ROOM TEMP
WATER SUPPLY TEMP
WATER SUPPLY PRESSURE 0.04-0.6 MPa
NOTE *: TESTED AT 70 Fahrenheit ROOM TEMPERATURE AND 50 Fahrenheit WATER TEMPERATURE.
Water
Inlet Port
Water
Drainage Port
50-110 Fahrenheit
41-95 Fahrenheit
