Kurth Electronic KE7200 - Applications

Operating Manual
KE7200 / KE7100
7
KURTH ELECTRONIC FERNMELDETECHNIK
www.kurthelectronic.de sales@kurthelectronic.de
Applications:
Testing and starting up 10/100/1000 Mbit LAN networks,
Verifying new LAN installations
Troubleshooting existing LAN installations
Logging network tests
Cable mapping
Fault finding
Testing PoE/PoE+/PoE++ performance
Measuring length, finding cables of all kinds, coaxial cables,
etc.
KE7200 only:
IP tests; static or with DHCP
Ping and stress tests
Storage of Measurements
Measurement and display of:
Cable test
- Mis-wiring
- Short circuit
- Open circuit
- Split pair
- Length of cables and wires with TDR up to 150 m
- External voltage
Power over Ethernet
- PoE Version A or B
- Available power in Watts according to IEEE 802.3af/at/bt
up to 90 watts
Cable/port
- Link Light Blink with Normal Link Pulse
- Transmit 4 different trace tones
