Basic Effects Mode
A Tour of Effects Mode
9-19
gain (to compensate for the treble boost), and full width. Play on the guitar part of the keyboard,
and the arrow next to B ßashes.
The other two inputs, C and D, are not assigned to any FXBus.
AuxFX Bus
Now letÕs look at the Auxiliary FX Bus (Aux bus). Press the AUXFX soft button to look at its
page.
Here is an FX preset called MedWarmPlate, which is just what it sounds like: a medium-sized,
warm-sounding plate reverb. It has two bus overrides, Wet/Dry mix, and Output Gain. The
Aux bus is sent to the main Mix bus at unity gain.
Since both Insert FXBuses have signal going to the Aux Bus, the arrow next to Aux will ßash as
long as any signal processing is going on in either of the insert FXBuses.
Outputs
Finally, press the OUTPUT soft button to get to the OUTPUT page. Here we see that the four
physical output pairs all are passing different parts of the studio. If the outputs are connected to
an external mixer, you can treat each of them separately: recording them on different tracks of a
tape deck, sending them to different outboard processors, or mixing them differently in a
monitor mix.
Output A has the Mix bus. This is the combined output of the two FXBuses, plus the reverb on
the Aux bus. Its gain and balance are at unity.
Output B has the output of FXBus1, that is, the ring-modulated piano, without any reverb.
Output C has the output of FXBus2, the delayed/ßanged/distorted guitar, without any reverb.
EditStudio:AUXFX|Size:3|Free:0||||||||||
||Aux||203*MedWarmPlate||||||||||Mix
|||Wet/Dry|||:100%wet|||||||||||Lvl:0.0dB
<more||INPUT||FXBUS||AUXFX||OUTPUT|more>
|||Out|Gain||:0.0dB|||||||||||||Bal:0%
EditStudio:OUTPUT||||||||||||||||||||||||
Mix|Lvl:0.0dB||||||Output|A:Mix
Mix|Bal:0%|||||||||Output|B:FXBus1
|||||||||||||||||||Output|C:FXBus2
|||||||||||||||||||Output|D:AuxFX
<more||INPUT||FXBUS|AUXFX||OUTPUT||more>||
