P 5.3
SECTION V
Parts Identification
PARTS COMMON - STANDARD
(Figure 5.1)
Item
No.
Part
No.
Description Qty.
1 00-000594 Hub - Models 100 & 200 1
00-000890 Hub - Model 300 1
00-000891 Hub - Model 400 1
00-001075 Hub - Model 500
2 *00-000673 Nut 4
3 00-000893 Spacer - Narrow
Models 100, 200, 300 1
00-000895 Spacer - Wide - Model 400 1
00-001076 Spacer - Frame - Model 500
4 00-001002 Frame - Main - Type A 1
5 00-001006 Plate - Top - Type A 1
6 00-001304 Enclosure - Electrical - Type A 1
7 00-001008 Cover - Electrical Enclosure 1
8 00-001046 Stand - Type A 1
9 00-001010 Cover - Access 1
10 00-001303 Shield 1
11 00-001047 Plate - Motor Mounting
Standard 1
12 00-001017 Post - Motor Mounting 4
13 00-001026 R Support - Wide - Type A
Model 400 1
00-001027 R Support - Narrow - Type A
Models 200 & 300 1
00-001028 R Support - Small - Type A
Model 100 1
00-001074 R Support - Frame - Type A
Model 500 1
Item
No.
Part
No.
Description Qty.
14 00-001026 L Support - Wide - Type A
Model 400 1
00-001027 L Support - Narrow - Type A
Models 200 & 300 1
00-001028 L Support - Small - Type A
Model 100 1
00-001074 L Support - Frame - Type A
Model 500 1
15 **P05-00019 Foot - Standard 4
*P05-00032 Cup - Suction 4
16 **P23-00286 Nut - Acorn 4
17 F04-190F S Nut - 10-32UNF - Hex 2
18 F11-190C06 S Screw - 10-24UNC x 3/8 Lg
Skt Btn Hd 2
19 F11-190F08 S Screw - 10-32UNF x 1/2 Lg
Skt Btn Hd 8
20 F11-164C04S Screw - 8-32UNC x 1/4 Lg
Skt Btn Hd 8
21 F11-190F06 S Screw - 10-32UNF x 3/8 Lg
Skt Btn Hd 12
22 **F13-250C06 Screw - 1/4-20UNC x 3/8 Lg
Hex Hd 4
23 *F14-187 Washer 4
24 P23-00061 Nut - 10-32UNF - ESNA 2
25 P23-00291 Screw - Phillips - Self Tapping 2
* These parts are available in kit Z0065004 Kit -
Suction Cups and may be ordered as such.
** These parts are available in kit Z0065006 Kit -
Feet and may be ordered as such.
PARTS LIST
086A 08 08
