Kwik Lok 086A - Page 25

P 5.7
SECTION V
Parts Identification
086A 03 03
PARTS COMMON 2
(Figure 5.3)
Item
No.
Part
No.
Description Qty.
1 00-001003 Track - Bottom 1
2 00-001004 Track - Top
Models - 300 & 400 1
00-001005 Track - Top
Models 100 & 200 1
3 00-001012 Lever - Sensor 1
4 00-001013 Mount - Stop 1
5 00-001014 Stop - Closure 1
6 00-001015 Strip - Wear 1
7 00-001018 Hub - Cam 1
8 00-001019 Cam 1
9 00-001020 Cam - Switch 1
10 00-001021 Block - Sensor Switch 1
11 00-001022 Pick 1
12 00-001023 Arm - Pick 1
13 00-001024 Anchor - Pick Spring 1
14 00-001025 Block - Cam Switch 1
15 00-001029 Check 1
16 08-002026 Pin - Drive 1
17 BS312203125 Bushing 1
18 BS375203375 Bushing 2
19 BS375257281 Bushing 1
20 OS-012 Spring 3
21 OS-117 Spring - Pick 1
22 P02-00064 Bearing - Pick 1
23 P12-00085 Switch - Limit 2
24 P23-00169 Pin - Drive 2
25 F01-190S Washer - No. 10 - Flat 1
26 F03-190FS Nut - 10-32UNF - Hex 4
27 F06-164C05 Screw - 8-32UNC x 5/16 lg
Skt Set 1
Item
No.
Part
No.
Description Qty.
28 F06-190C06 Screw - 1/4-20UNC x 3/8 Lg
Skt - Set 1
29 F07-164C10S Screw - 8-32UNC x 5/8” Lg
Mach Hd 1
30 F10-112C10S Screw - 4-40UNC x 5/8 Lg
Skt Hd Cap 2
31 F10-112C16S Screw - 4-40UNC x 1” Lg
Skt Hd Cap 2
32 F10-250C12 Screw - 1/4-20UNC x 3/4 Lg
Skt Hd Cap 1
33 F11-190F04S Screw - 10-32UNF x 1/4 Lg
Skt Btn Hd 2
34 F11-190F05S Screw - 10-32UNF x 5/16 Lg
Skt - Btn Hd 1
35 F11-190F07S Screw - 10-32UNF x 7/16 Lg
Skt Btn Hd 1
36 F11-190F10S Screw - 10-32UNF x 5/8 Lg
Skt Btn Hd 2
37 F07-190F28S Screw - 10-32UNF x 1 3/4
Mach Hd 1
38 F12-138C06S Screw - 6-32UNC x 3/8 Lg
Skt Flt Hd 3
39 F12-164C06S Screw - 8-32UNC x 3/8 Lg
Skt Flt Hd 3
40 F12-190F06S Screw - 10-32UNF x 3/8 Lg
Skt Flt Hd 4
41 F12-190F10S Screw - 10-32UNF x 5/8 Lg
Skt Flt Hd 4
42 F03-164C Nut - 8-32UNC - Hex 2
43 OS-118 Spring 2
PARTS LIST
