－－28－－28
9. EASY MAINTENANCE9. EASY MAINTENANCE
(1) AIR CLEANER INSPECTION AND AIR CLEANER
CLEANING & REPLACEMENT
(1) AIR CLEANER INSPECTION AND AIR CLEANER
CLEANING
& REPLACEMENT
Take out the air cleaner and visually check if it is dirty or
clogged.
1.Remove the screws attaching the air cleaner cover and
remove the air cleaner cover.
2.Remove the air cleaner element.
3.The installation sequence is the reverse of removal.
Soak the element in clean engine oil and squeeze out the excess oil
and then install the element and air cleaner. Replace the air cleaner
element at very 2000km. The air cleaner requires more frequent
cleaning or replacing when ridden in unusually dusty areas. When
replacing, refer to P40 Periodic Inspection & Maintenance Schedule.
Take out the air cleaner and visually check if it is dirty or
clogged.
1.Remove
the screws attaching the air cleaner cover and
remove
the air cleaner cover.
2.Remove
the air cleaner element.
3.The
installation sequence is the reverse of removal.
Soak
the element in clean engine oil and squeeze out the excess oil
and
then install the element and air cleaner. Replace the air cleaner
element
at very 2000km. The air cleaner requires more frequent
cleaning
or replacing when ridden in unusually dusty areas. When
replacing,
refer to P40 Periodic Inspection & Maintenance Schedule.
Be careful not to allow water to enter the air cleaner;
otherwise it may result in hard starting.
If the air cleaner is not installed properly, dust may be
sucked into the cylinder directly to reduce engine
horsepower and affect the service life of engine.
Be careful not to allow water to enter the air cleaner;
otherwise
it may result in hard starting.
If
the air cleaner is not installed properly, dust may be
sucked
into the cylinder directly to reduce engine
horsepower
and affect the service life of engine.
CAUTION:
Never use oil or solvent to wash the wet type paper
element.
Never use oil or solvent to wash the wet type paper
element.
Screw
To Next Page
