8. DRIVE AND DRIVEN PULLEYS/
KICK STARTER
8-9
Bet & Win 2 50
Check the clutch shoes for wear or damage.
Measure the clutch lining thickness.
Service Limit: 2.0mm replace if below
CLUTCH/DRIVEN PULLEY
DISASSEMBLY
Hold the clutch/driven pulley assembly with
the clutch spring compressor.
Clutch Spring Compressor
Set the tool in a vise and remove the clutch
drive plate nut.
Lock Nut Wrench, 39mm
Loosen the clutch spring compressor and
disassemble the clutch/driven pulley
assembly.
Remove the seal collar.
Clutch/Driven Pulley
Special
Clutch Spring Compressor
• Be sure to use a clutch spring
compressor to avoid spring damage.
＊
Lock Nut Wrench
www.PlanDeGraissage.org

KYMCO Bet & Win 250 Specifications

General

Displacement	249.4 cc
Cooling System	Liquid-cooled
Fuel System	Carburetor
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Fuel Capacity	12 liters
Ignition	CDI
Width	770 mm
Height	1, 370 mm
Seat Height	780 mm
Engine Type	4-stroke, single-cylinder
