KYMCO MAXER User Manual

PRODUCT SPECIFICATIONS
5
5
.
.
P
P
R
R
O
O
D
D
U
U
C
C
T
T
S
S
P
P
E
E
C
C
I
I
F
F
I
I
C
C
A
A
T
T
I
I
O
O
N
N
S
S
Model Name EQ40DA(UK)
Maximum weight capacity
440 lbs (200kg)
Overall height 43.3 in (1100 mm)
Overall length 58.7 in (1490 mm)
Overall width 24.2 in (615 mm)
Drive System
Rear-wheel drive, sealed
transaxle, 24-volt DC motor
Battery 12 V × 80 Ah × 2 Pcs
Battery charger
Off-board
Input voltage : 200/250VAC,
Output voltage : 24VDC
Output current : 8A
Front wheel Pneumatic, 13 in*2
Rear wheel Pneumatic, 13 in*2
Rear wheel drive system
Sealed transaxle drive with
differential
Braking system
Primary-motor
electromagnetic brake
Secondary-hand brake
Maximum incline angle 12 degree
Per-charge Run distance
Up to 35 miles (57km)
Maximum speed
Forward
8mph (12.8 kph)
Backward
2.78mph (4.5 kph)
Turning radius 83.7 in (2125 mm)
Overall height of seat
26.1 in (663 mm) (from
ground)
Overall width of seat 18.5 in (470 mm)
Overall depth of seat 18.9 in (480 mm)
Overall weight of seat 43 lbs (19.5 kg)
17

KYMCO MAXER Specifications

General

Transmission	CVT
Front Suspension	Telescopic fork
Tires (Front)	120/70-12
Tires (Rear)	130/70-12
Seat Height	780 mm
Max Torque	3.2 Nm @ 6500 rpm
Starting System	Electric
Front Brake	Disc
Rear Brake	Drum
Length	1920 mm
