5. FUEL SYSTEM
5-13
CAUTIONS!
ASSEMBLY
Reverse the “DISASSEMBLY” procedures.
• Be careful not to damage the jets an
jet holder when removing them.
• Before removal, turn the throttle stop
screw and air screw in and count the
number of turns until they seat lightly
and then make a note of this.
• Do not force the screw against its seat
to avoid seat damage.
• Be sure to install the O-ring in the
reverse order of removal.
＊
Throttle Stop Screw
SpringAir Screw
Spring
Washe
• When installing the air screw, return it
to the original position as noted during
removal
• Refer to the “CARBURETOR IDLE
SPEED” section in chapters to perform
the idle speed adjustment.
• After the carburetor is installed, be
sure to perform the Exhaust Emission
To Next Page
