4. LUBRICATION SYSTEM
4-16
OIL TANK (50cc-2T)
OIL TANK REMOVAL
Remove the oil level switch connector.
Remove the two bolts attaching the oil tank.
Disconnect the oil inlet tube.
Drain the oil inside the oil tank into a clean
container.
Remove the oil tank.
The installation sequence is the reverse of
removal.
• Connect the oil tube properly.
• Bleed air from the oil pump after
installation. (See page 4-15)
• The oil tube clip (at the oil tank side)
must be locked from inside of the oil
tube joint.
＊
Oil Level Switch Connecto
To Next Page
