KYMCO MXU 150 - Transmission Oil

135
TRANSMISSION OIL
Transmission oil replacement
1. MXU 300/250:
Remove 6 screws/nuts, 4 bolts and right
footboard. (Page 54)
2. Place the machine on a level place.
3. Place a container under the engine.
4. Remove the oil filler bolt .
MXU 300
MXU 250
(1) Oil filler bolt
(1)
(1)
(1) Oil filler bolt
MXU 150
(1) Oil filler bolt
(1)
