3. Remove the drain plug.
4. After the oil has completely drained,
reinstall the drain plug.
5. Fill the gear case with the recommended
oil.
Remove the oil level check bolt (3).
Make sure the oil level reaches the oil
level check hole.
6. Install the oil filler cap and oil level check
bolt.
(3) Oil level check bolt
Tightening torque
Drain plug: 20 Nm (2 m-kg, 15 ft-lb)
(3)
139
Recommended oil : SAE 90
Oil quantity :
Periodic oil change
0.1L(3.56lmpoz,3.33USoz)
Tightening torque:
Oil filler cap: 14.7 Nm (1.5 m-kg, 11 ft-lb)
Oil level check bolt:
20 Nm (2 m-kg, 15 ft-lb)
