5. Remove the screw (6) and remove the air
cleaner assembly from the air cleaner holder.
6. Remove the air cleaner (7) and air cleaner
screen ( 8) from the air cleaner guide (9).
7. Remove the air cleaner screen from the air
cleaner.
(6)
(6) Screw
(7) (8) (9)
(7) Air cleaner
(8) Air cleaner screen
(9) Air cleaner guide
142
