KYMCO MXU 150 - Page 164

(1) Rear brake pads cover (Rear brake lever)
(2)
Wear indicator
Rear brake pads (Rear brake lever)
(3)
(1) Rear brake pads cover (Rear brake pedal)
(2)
Wear indicator
Rear brake pads (Rear brake pedal)
(3)
(2)
(1)
(3)
(2)
(3)
(1)
Rear brake pads (MXU 250) inspection
A wear indicator is provided on each brake. The
indicators allows checking of brake pads
wear.Check the position of the indicator. If the
indicator reaches the wear limit line, ask a
KYMCO dealer to replace the pads.
