14. STEERING HANDLEBAR/FRONT WHEEL/FRONT
BRAKE/FRONT SHOCK ABSORBER/FRONT FORK
14-5
People GT 300i
Lubricate the throttle grip front end with
grease and then install the throttle grip.
Connect the throttle cable to the throttle grip.
Install the right and left handlebar switches
and tighten the screws.
Install the front and rear brake master
cylinders.
FRONT WHEEL
REMOVAL
Disconnect the speed wire from the front right
suspension unit.
Remove the front axle to pull out the axle.
Remove the front wheel.
INSPECTION
AXLE RUNOUT
Set the axle in V blocks and measure the
runout using a dial gauge.
The actual runout is ½ of the total indicator
reading.
Service Limit: 0.2 mm replace if over
• Adjust the throttle grip free play to the
specified range of 2～6mm.
＊
• Install the brake master cylinders by
aligning the index marks.
＊
Front axle
Throttle Grip
Throttle Cable
Colla
To Next Page
