19. LIGHTS SWITCHES/ FUEL PUMP
19-2
People GT 300i
SERVICE INFORMATION
GENERAL
• Note the following when replacing the halogen headlight bulb
ä Wear clean gloves while replacing the bulb. Do not put finger prints on the headlight bulb,
as they may create hot spots on the bulb and cause it to fail.
ä If you touch the bulb with your bare hands, clean it with a cloth moistened with alcohol to
prevent its early failure.
ä Be sure to install the dust cover after replacing the bulb.
• Check the battery condition before performing any inspection that requires proper battery voltage.
• A continuity test can be made with the switches installed on the scooter.
• Route the wires and cables properly after servicing each component.
TROUBLESHOOTING
Lights do not come on when ignition Temperature gauge does not register
switch is “ON” correctly
• Burned bulb • Faulty temperature gauge
• Faulty switch • Faulty thermosensor
• Poorly connected, broken or shorted wire • Broken or shorted wire between
the temperature gauge and thermosensor
Fuel gauge does not work or
wrong show figures
• Faulty fuel gauge
• Faulty fuel unit
• Poorly connected wire between fuel
gauge and fuel unit
• Fuse burned out
SPECIFICATIONS
Fuse 10A/15A/30A
Headlight bulb 12V 60W/55W
Turn signal light bulb 12V10W/2W (LED)
Stoplight/taillight 12V 21/5W
A halogen head light bulb becomes very hot while the head light is on, and remains for a while
after it is turned off. Be sure to let it cool down before servicing.
＊
