12
. FRONT WHEEL/FRONT BRAKE/
FRONT SUSPENSION
12-4
PEOPLE S 4T
FRONT WHEEL
REMOVAL
Remove the motorcycle front wheel off the
ground.
Disconnect the speedometer cable.
Remove the front axle nut and pull out the
axle.
Remove the front wheel.
Remove the front brake panel.
INSPECTION
AXLE RUNOUT
Set the axle in V blocks and measure the
runout using a dial gauge.
The actual runout is 1/2 of the total indicator
reading.
Service Limit: 0.2mm replace if over
WHEEL RIM
Check the wheel rim run-out.
Service Limits:
Radial: 2.0mm replace if over
Axial: 2.0mm replace if over
Speedometer Cable
A
xle Nut
A
xle Shaft
