djusting
the seat height
20
The seat height (h) is adjusted using the
five holes (1-4) in the seat support.
Pull the seat support (4) out as far as
the required height until the correct
hole (1-4) appears in the seat tube
hole (5).
Push the clamping bolts (6) into the seat
tube from the front.
h
4 holes
~
In order to avoid danger
when driving. Please
adjust the height of seat,
and then confirm if the
seat’s bolt is at the right
position, otherwise, the
seat would be shaked.
