6. ENGINE REMOVAL/INSTALLATION
6-3
SUPER8 50
Loosen the drive belt air cleaner connecting tube
band screw and remove the connecting tube.
Remove the rear brake adjusting nut,
connector pin rear brake cable.
Remove the L/R side the rear shock absorber
upper mount bolts.
Remove the engine mounting bolt and move
the motorcycle forward to separate it from the
engine.
Support the motorcycle with a floor jack.
Rear Shock Absorber Upper Mount Bol
t
connecting tube
Air Tube Band
Adjusting Nut
Engine Mounting Bol
t
Engine Hange
r
Bracket Bolt
