8. CYLINDER/PISTON
8-2
SUPER8 50
CYLINDER REMOVAL
Remove the cylinder head. (
Ö
7-6)
Remove the cam chain guide.
Remove the cylinder.
Remove the cylinder gasket and dowel pins.
Clean any gasket material from the cylinder
surface.
PISTON REMOVAL
Remove the piston pin clip.
Press the piston pin out of the piston and
remove the piston.
Dowel Pins
Gaske
t
C
y
linde
r
Piston
Piston Rin
g
s
Place a clean shop towel in the crankcase
to keep the piston pin clip from falling
into the crankcase.
＊
Piston Pin
