Kyocera DF-420 - Maintenance Parts List; Periodic Maintenance Procedures; 2-4 Appendixes

3MJ
2-4-1
2-4 Appendixes
Maintenance parts list
Periodic maintenance procedures
Maintenance part name
Part No.
Alternative
part No.
Fig.
No.
Ref.
No.
Name used in service manual Name used in parts list
Process table - - - 3 -
Upper curl eliminator roller UPPER ROLLER DECURLER 3HP08110 - 2 27
Lower curl eliminator roller ROLLER DECURLER 303HP08101 3HP08101 1 33
Eject roller ROLLER EJECT 303HP08121 3HP08121 1 21
Eject pulleys PULLEY,LOOP FEED 63210170 - 1 41
Feedshift roller ROLLER FEED SHIFT 303HP08091 3HP08091 1 32
Feedshift pulleys PULLEY,BRANCH 3BN08100 - 2 38
Press roller PULLEY STOPPER PRESSURE 3HP08390 - 1 13
Switches and sensors - - - - -
Section
Maintenance
part/location
Method Maintenance cycle Points and cautions Page
Paper con-
veying and
process table
section
Process table Clean and
grease
Every service Clean the rail section and
apply molycote grease EM-
50L/50G.
Upper curl eliminator
roller
Clean Every service Clean with alcohol. (Check
and clean with alcohol when
user call occurs.)
Lower curl eliminator
roller
Clean Every service Clean with alcohol. (Check
and clean with alcohol when
user call occurs.)
Eject roller Clean Every service Clean with alcohol. (Check
and clean with alcohol when
user call occurs.)
Eject pulleys Clean Every service Clean with alcohol. (Check
and clean with alcohol when
user call occurs.)
Feedshift roller Clean Every service Clean with alcohol. (Check
and clean with alcohol when
user call occurs.)
Feedshift pulleys Clean Every service Clean with alcohol. (Check
and clean with alcohol when
user call occurs.)
Press roller Clean Every service Clean with alcohol. (Check
and clean with alcohol when
user call occurs.)
Switches and sensors Clean Every service Airbrush.
