2-27
The main unit setup procedure > Installation
[CONFIDENTIAL]
4
Remove the cap [A] and reattach the spacer [B].
5
Put the cap [A] on top again.
6
Close the cleaning liquid tank cover [A] and lock by rotating the lock lever [B].
7
Close the front left lower cover [A].
IMPORTANT
Do not tighten the cap but just put on.
[A] [A][B]
[A]
[B]
[A]
