Chapter 7 Emulation
7-110
KC-GL Limits
This section provides limit values for the various KC-GL parameters. Plotter units are
used unless otherwise specified.
Standard Character Sizes
Maximum Plot Area
Coordinate Values
Table 7.33. Standard Character Sizes
Paper size Width (mm) Height (mm)
A4 0.187 0.269
A3 0.285 0.375
Letter 0.187 0.269
Ledger 0.285 0.375
Table 7.34. Maximum Plot Area
Paper size X Y
Plotter units Dots Plotter units Dots
A4 11477 3389 7999 2362
A3 16398 4842 11487 3392
Letter 10776 3182 8236 2432
Ledger 16872 4982 10776 3182
Table 7.35. Coordinate Values, Mode A, RO 0
Paper size P1x P1y P2x P2y
A4 430, 200 10430, 7400
A3 380, 430 15580, 10430
Letter 80, 320 10080, 7520
Ledger 620, 80 15820, 10080
Table 7.36. Coordinate Values, Mode A, RO 90
Paper size P1x P1y P2x P2y
A4 200, 430 7400, 10430
A3 430, 380 10430, 15580
Letter 320, 80 7520, 10080
Ledger 80, 620 10080, 15820
Table 7.37. Coordinate Values, Mode B, RO 0
Paper size P1x P1y P2x P2y
A4 –4700, –2480 4700, 2480
A3 –6680, –4700 6680, 4700
Letter –4348, –2598 4348, 2598
Ledger –6916, –4348 6916, 4348
