2PK/2PL/2PM/2PN
1-3-74
U917 Setting backup data reading/writing
Description
Retrieves the backup data to a USB memory from the machine; or writes the data from the USB
memory to the machine.
Purpose
To store and write data when replacing the control PWB.
Method
1. Press the power key on the operation panel, and after verifying the power indicator has gone
off, switch off the power switch.
2. Insert USB memory in USB memory slot.
3. Turn the power switch on.
Wait for 10 seconds to allow the machine to recognize the USB memory.
4. Enter the maintenance item.
5. Press the start key.
6. Select [Export] or [Import] using the cursor up/down keys and press the start key.
7. Select the item using the cursor up/down keys.
* : Since data are dependent with each other, data other than those assigned are also
retrieved or written in.
8. Select [ON] using the cursor left/right keys.
9. Press the start key. Starts reading or writing.
The progress of selected item is displayed in %.
When an error occurs, the operation is canceled and an error code is displayed.
10. When normally completed, [FIN] is displayed.
11. Turn the power switch off and on after completing writing when selecting [IMPORT].
Item No. Description
Display Description
IMPORT Writing data from the USB memory to the machine
EXPORT Retrieving from the machine to a USB memory
Display Description Depending data
ADDRESS
BOOK
Address book -
JOB ACCNT. Job accounting -
ONE TOUCH Information on one-touch key Address book
USER User managements Job accounting
PROGRAM Program information Job accountings and user manage-
ments
DOCUMENT
BOX
Document box information Job accountings and user manage-
ments
FAX
FORWARD
FAX transfer information Job accountings, user managements
and document box information
To Next Page
