Kyocera ECOSYS M2530dn

2PK/2PL/2PM/2PN
1-4-12
3200 Exposure lamp error
The exposure lamp is not turned on.
Defective FFC
between scan-
ner PWB
(YC103) and
control PWB
(YC6), or
improper FFC
insertion.
Reinsert the FFC. Also check for conti-
nuity within the FFC. If none, remedy or
replace the FFC.
Defective FFC
between CCD
PWB (YC1) and
control PWB
(YC8).
Replace the image scanner unit (ISU)
(See page 1-5-21).
Defective har-
ness between
CCD PWB (YC3)
and LED drive
PWB (YC1), or
improper con-
nector insertion.
Reinsert the connector. Also check for
continuity within the connector har-
ness. If none, remedy or replace the
harness.
Defective har-
ness between
LED drive PWB
(YC2) and expo-
sure lamp, or
improper con-
nector insertion.
Reinsert the connector. Also check for
continuity within the connector har-
ness. If none, remedy or replace the
harness.
Defective expo-
sure lamp.
Replace the exposure lamp (See page
1-5-27).
Defective LED
drive PWB.
Replace the LED drive PWB (See page
1-5-27).
Defective control
PWB.
Replace the control PWB (See page 1-
5-37).
3300 AGC error
After AGC, correct input is not
obtained at CCD.
Defective FFC
between CCD
PWB (YC1) and
control PWB
(YC8).
Replace the image scanner unit (ISU)
(See page 1-5-21).
Defective expo-
sure lamp.
Replace the exposure lamp (See page
1-5-27).
Defective CCD
PWB.
Replace the CCD PWB.
Defective control
PWB.
Replace the control PWB (See page 1-
5-37).
Code Contents
Remarks
Causes
Check procedures
/corrective measures
